Buttweld
Fittings
At Metrade, we specialize in providing top-quality Buttweld fittings that are engineered for durability, precision, and performance. Designed for applications where long-term reliability and pressure resistance are critical, our Buttweld fittings are the go-to choice for a wide variety of industrial systems. They offer seamless, high-strength connections that minimize the risk of leakage and maximize the integrity of your piping network.
Buttweld fittings are a type of pipe fitting used to connect pipes, valves, or equipment by welding the fitting directly to the pipe. These fittings are commonly used in systems that require strong, permanent, and leak-proof connections. The term “buttweld” refers to the process where the ends of the pipes or fittings are butted together and then welded along the joint to create a secure connection.
Material | Specification | Grades |
---|---|---|
Carbon Steel | ASTM A234 | WPB |
Low Temperature Carbon Steel | ASTM A420 A860 | WPL6, WPL9, WPL3, WPL8 WPHY42, WPHY46, WPHY52, WPHY60, WPHY65, WPHY70 |
Stainless Steel and Special Stainless Steel | ASTM A403 ASTM A815 | WP 304/304L, WP 316/316L, WP310, 317, 321, 347, 410, 904, WP S31254, UNS N08367, UNS N08926 UNS S31803 – Duplex 32205 UNS S32750 / S32760 / S32550 – Super Duplex |
Alloy Steel | ASTM A234 | AISI 4130 |
Nickel Alloy 200/201 | B366 | UNS N02200/N02201 |
Nickel Alloy 276 | B366 | UNS N10276 – Hastelloy C-276 |
Nickel Alloy 400 | B366 | UNS N04400 – Monel 400 |
Nickel Alloy 600 | B366 | UNS N06600 – Inconel 600 |
Nickel Alloy 625 | B366 | UNS N06625 – Inconel 625 |
Nickel Alloy 800H/800HT | B366 | UNS N08810/N08811 – Incoloy 800H/HT |
Nickel Alloy 825 | B366 | UNS N08825 – Incoloy 825 |
Titanium Alloy | B862 | Gr 1 / 2 / 5 / 7 |
